High-Performance 3-Row Aluminum Radiator for Dodge D100 D150 D200 W100 W200 V8 5.2L 5.9L (1971-1979) - Includes Cooling Fan Shroud & Thermostat Relay Kit - Perfect for Engine Cooling & Off-Road Adventures

Product Description

Application Fits 1971-1979 Dodge B/D/W Series Pickup Van B100, B100 Van, B200, B200 Van, B300, B300 Van, D100, D100 Panel, D100 Pickup, D150, D200, D200 Pickup, D300, D300 Pickup, D400, D450, Ramcharger, W100, W100 Pickup, W150, W200, W200 Pickup, W300, W300 Pickup This radiator is designed for either a 5.2L(318ci) V8, 5.9L(360ci) V8, 6.6L(400ci) V8 or a 7.2L(440ci) V8 engine Part Number 889,CU889,CC889,DPI889,MC889 This Listing Is Including 1 X 3-Row Aluminum Radiator (Includes Radiator Cap) 1 X Aluminum Shroud 1 X 16" Fan (Includes mounting kits) 1 X Thermostat Relay Kit Radiator Details Core Row: 3 Row Core Material: All Aluminum Tank Material: All Aluminum Radiator Cap: Included Radiator Flow: Cross Flow Mounting Type: Bracket Style The tanks are 100% welded by TIG CNC machined filler neck and cap OEM style brass petcock drain High Performance Racing Spec Fan Specification Maximum Fan CFM: 2000±200 cfm Fan Diameter (in): 16.050” Thickness (in): 2.790" Number of Blades: 10 blades Maximum Fan RPM: 2,250 rpm Blade Material: Plastic Amp Draw: 12.70 amps Includes the Mounting Tabs for an Easy Zip Tie Installation Relay Kit Instructions RED + connect directly to battery WHITE wire to ignition switch power source BLACK goes to thermos switch BLUE wire goes to the Fans Why Choose CoolingSnow Radiator? 1. Maximum cooling efficiency 2. High security and performance 3. Excellent aluminum material 4. Stability and durability 5. Drop-in installation 6. High temperature resistance 7. Enhanced protection package
