17 Row Transmission Oil Cooler with 6" Electric Fan & Adjustable Thermostat Switch Kit - Heavy Duty Cooling for Trucks, RVs, and Performance Vehicles

Product Description

Fluid Cooler:Universal 17 row plate and fin aluminum heavy duty transmission cooler kit.Extend transmission life by helping prevent heat-related transmission failures.Perfect for light to medium duty truck, car or RV use and occasional towing.7/8" wide plates, 3/4" embossed turbulators which maximizes heat transfer.Dimensions: 0.75" x 7.5" x 11" with 3/8" hose barb inlets, GVW 18000 lbs.Electric Fan:Universal 12 volt high performance 6" inch small electric cooling fan.Upgraded 90 watt motor draws 7.5 amps, producing over 513 CFM.Configured as an air puller to be on the inside and pull air through.Includes mounting bracket feet and complete install fin tie strap kit.Measures 7.2" x 7" x 2.4" thickness at center and slim 1.4" at edge.Wiring Kit:Universal automotive 12 volt electric fan switch relay wire harness.Safely powers one 12 volt cooling fan or accessory without splicing.Maximum continuous draw with 40 amp circuit breaker protection.Simple 4 pin relay 40A and 6 feet of 14AWG wiring allows flexibility.Installation wiring diagram and all pictured components included.Thermostat:Universal adjustable automotive electric fan thermostat switch sensor.Turn-on range of 32-248'F with turn-off always set at 15 degrees less.3 pin design allows for wiring as a normally open or closed circuit.Probe pushes between radiator fins or inserts into coolant hose line.Detailed install instructions, wiring diagram and hardware included.
