2003-2007 Ford Excursion F250 F350 F450 Super Duty 6.0 Powerstroke Diesel Aluminum Radiator Kit - 1 Row Downflow Design with Dual Electric Fan Shroud & Thermostat - Heavy Duty Cooling Solution for Towing, Off-Road & Extreme Weather Conditions

Product Description

Compatible with: Direct fit for 2003–2007 Ford trucks equipped with the 6.0L Powerstroke 2003-2005 Ford Excursion Powerstroke Diesel 6.0L (Automatic Transmission) 2003-2007 Ford F-250 Powerstroke Diesel 6.0L (Manual And Automatic Transmission) 2003-2007 Ford F-350 Powerstroke Diesel 6.0L (Manual And Automatic Transmission) 2003-2007 Ford F-450 Powerstroke Diesel 6.0L (Manual And Automatic Transmission) Radiator Details: Type: 1 Core Core Thickness: 1.02" Upgraded Drain Plug: OEM Style Brass Petcock Drain Drain Plug Thread：M12 x 1.5 TOC Thread: M18 x 1.5 Transmission Oil Cooler: YES Delivery: Local Delivery Performance: Up to 30%-45% Cooling FAN SPEC: Maximum Fan CFM: 2300±200 Fan Diameter X Height X Thickness:12.05" X 12.05" X 2.5" Number of Blades: 10 blades (Plastic) Amp Draw: 12.70 amps Maximum Fan RPM: 2,250 rpm Thermostat Kit: Universal fit for any automotive vehicle and electric fan. Activates by grounding electric fans at preset temperature. 180'F turn-on temperature, 165'F turn-off temperature. 3/8" NPT thread-in brass probe included. Probe typically threads into radiator, water outlet or manifold. Thermostat Relay Kit Instructions： RED + connect directly to battery. WHITE wire to ignition switch power source. BLACK goes to thermos switch. BLUE wire goes to the Fans. Package Include: 1 X 1-Row Aluminum Radiator (Includes Radiator Cap) 1 X Aluminum Shroud 2 X 12"Fan (Includes mounting kits) 1 X Thermostat Relay KitCOOLINGBEST Radiador: 1.Shuttered design T-5052 fan shroud to guaranteed airflow passes high efficiently. Make your engine bay perfect! 2. S blade fans, Push or Pull Type design,lightweight Plastic Durable Material. 3. Additional with thermostat,professional matching advice, consider for every detail and needed.
