High-Performance 3-Row Aluminum Radiator for 1987-2006 Jeep Wrangler TJ - Compatible with 2.4L 2.5L L4 & 4.0L 4.2L L6 Gas Engines - Includes Cooling Fan, Shroud & Thermostat Relay Kit - Perfect for Off-Roading & Extreme Weather Conditions
Delivery & Return:Free shipping on all orders over $50
Estimated Delivery:7-15 days international
People:6 people viewing this product right now!
Easy Returns:Enjoy hassle-free returns within 30 days!
Payment:Secure checkout
SKU:23609238
Product Description
This Radiator Compatible with: Jeep TJ 2.4L L4, 2003, 2005-2006 Jeep TJ 2.5L L4, 1997-2002 Jeep TJ 4L L6, 1997-2006 Jeep Wrangler 2.4L L4, 2003-2006 Jeep Wrangler 2.5L L4, 1987-1995, 1997-2002 Jeep Wrangler 4.2L L6, 1987-1990 Jeep Wrangler 4L L6, 1991-1995, 1997-2006 PLS check core/overall/inlet/outlet SIZE carefully before you order OE/OEM Part Number: 2101, CC2101, AE2101, EC2101, MC2101, DPI2101, DPI16, CU2101, 2102-2AA Interchange Part Number: 5102983AA, 52028041, 52028123, 52029121, 52029122 Superseded Part Number: 52080180, 52080181, 52080183, 52080184, RA-JEEP87-3 Radiator Specs: High Performance Racing Spec. 3-Row of tubes Core Racing Design Transmission Oil Cooler: Included Tank Material: Full Aluminum Core Material: All Aluminum Flow Type: Downflow Delivery: Local Delivery Crafts: 100% Tig welded Mounting Type: bracket OEM Style Brass Petcock Drain Includes CNC machined filler neck and cap Fan Size: 16inch Fan Voltage: DC 12 Volts Maximum Fan CFM: 2150 cfm Wattage: 120 Wattage Thickness (in): 2.500 Number of Blades: 10 S-Type blades Maximum Fan RPM: 2,250 rpm Amp Draw: 10 amps Thermostat Relay Kit Instructions: RED + connect directly to battery WHITE wire to ignition switch power source BLACK goes to thermos switch BLUE wire goes to the Fans PLS use AmazonConfirmedFit to confirm this radiator fit your vehicle before you order This aluminum radiator is big and easy got damaged during shipping, PLS contact us and offer us pics of damage details if the radiator or packing box arrived damaged. We responsible for this
Product Features
Core Size(inch) 18 1/2 x 20 x 1.74 Thickness / Overall Size(inch) 23 1/2 x 25 1/2 / Rows 3
Inlet Hose Connection (inch) 1 1/4 Passenger Side / Outlet Hose Connection (inch) 1 1/2 Driver Side
Build-in Transmission oil cooler size 305×M16x1.5（Z)
All aluminum design with durable TIG-welded construction
100% brazed aluminum core, TIG-welded to aluminum end tanks
Use of Nitrogen during welding in the furnace for maximum strength
KUUHLERSAT Radiator Come with durable 3 row core design radiator & upgraded fan set
This AA5052 Aluminum Radiator is at least 30%-45% more efficient than stock ones
Direct bolt-on OE fitment or replacement for factory unit, fast and simple installation design
